Siemens - WLAN Access Point - 6GK5788-2GD00-0TA0
Aanbevelingen
Productomschrijving
6GK5788-2GD00-0TA0 SCALANCE SCALANCE W788-2 M12 ECC
IWLAN Access Point, SCALANCE W788-2 M12 EEC, 2 radios, 6 N-CON antenna port, iFeatures support via key plug, IEEE 802.11a/b/g/h/n, 2.4/5GHz, gross 450 Mbit/s per radio, 1x M12 max. 1 Gbit/s, PoE, redundant 24 V DC,M12 A-coded IP65, -40..+70 °C, plug slot,
IWLAN Access Point, SCALANCE W788-2 M12 EEC, 2 radios, 6 N-CON antenna port, iFeatures support via key plug, IEEE 802.11a/b/g/h/n, 2.4/5GHz, gross 450 Mbit/s per radio, 1x M12 max. 1 Gbit/s, PoE, redundant 24 V DC,M12 A-coded IP65, -40..+70 °C, plug slot, WPA2/802.11i/e,conformal coating EN 50155, EN 45545, observe national approvals! CERT ID: RAPN-W2-M12-E3, includes: MPCIE-R1-ABGN-U3, scope of delivery: Manuals on CD-ROM, German/English, M12 sealing caps, for operation outside of USA/Israel SCALANCE W788-2 M12 EEC 2 wireless, 6x N-CON antenna port, iFeatures support via KEY-PLUG, IEEE 802.11a/b/g/h/n, 2.4/5 GHz, gross 450 Mbps per wireless, 1x M12 max. 1 Gbps, PoE, redundant 24 V DC, M12 A-coded IP65, -30 °C - +70 °C, plug slot, for operation outside the US/Israel. Access Point for wireless on-site networking of plant parts with a requirement for high bandwidths. 1 unit
Specificaties
Algemeen
| Ons artikelnummer | 1154562 |
| Artikelnummer fabrikant | 6GK57882GD000TA0 |
| EAN-code | 4019169310390 |
| Artikelklasse (ETIM) | WLAN Access Point |
| Merk | Siemens |
| Serie | |
| Type nummer | 6GK5788-2GD00-0TA0 |
| Omschrijving | IWLAN AP, 450 Mbps, M12, EEC, 2x wireless, 6x N-Connect, PLUG slot |
| Land van Oorsprong | DE |
Technisch
| Ethernet | Ja |
| Max. overdraagsnelheid | 450 Mbps |
| Managed | Ja |
| Radioprotocol | IEEE 802.11 a |
| Versleuteling | IEEE 802.11 i |
| Breedte | 0.2 mm |
| Aantal poorten 10/100 Mbps LAN | 1 |
| Geïntegreerde firewall | Nee |
| VPN-Security | Nee |
| Aansluiting voor externe antenne | Ja |
| Bridge-functie | Ja |
| Repeaterfunctie | Ja |
| Power over Ethernet | Ja |
| Hoogte | 0.176 mm |
| Diepte | 0.079 mm |
| Kleur | Overig |
| Frequentieband | 2,4 GHz en 5 GHz |
| Aantal poorten 10/100/1000 Mbps LAN | 1 |
| Beschermingsgraad (IP) | IP65 |
| Inbouw | Nee |
| Inbouwmontage (stucwerk) | Nee |
| Geschikt voor wandmontage | Ja |
| Plafondmontage | Nee |
| Mastbevestiging | Nee |
| Contactdoosadapter | Nee |
| Aantal poorten 10 Gbps Mini GBIC | 0 |
| Firewall doorvoer | 0 Gbit/sec. |
| Geschikt voor 19 inch montage | Nee |
| Aantal gebruikers | 8 |
Logistiek
| Levertermijn | Levertermijn op aanvraag |
| Aantal eenheden in artikel | 1 st |
| Minimale bestelafname | 1 st |
| Standaard voorraadartikel | Nee |
| Bruto gewicht | 2,162 kg |
| Afmeting verpakking | 0,29 x 0,263 x 0,192 m |
Prijs
| Bruto prijs (€) | 2.550,00 per 1 st |
