Schneider Electric - Ruimtetemperatuurregelaar bussysteem - MTN616725

MTN616725 KNX THERMOST./4-V. DK-INTERF., AW,SYST M

KNX inbouw temp.regelaar - PI impulsdrukkerinterface -4V- Actief wit - Systeem M

KNX Room temperature control unit, flush-mounted/PI with 4-gang push-button interface. For System M. The device is a room temperature control unit and a binary input. Depending on the operating mode, the current temperature setpoint value and the room temperature, a control value for the heating or cooling control unit is transmitted to the KNX. The temperature can either be recorded by the internal or the external temperature sensor which must be connected to the push-button interface. The push-button interface generates an internal signal voltage for connecting max. four conventional push-buttons or floating contacts. Of these, two inputs can be used to connect low current LEDs. With integrated bus coupler. The bus is connected using a bus connecting terminal. Functions of the room temperature control unit: Controller type: 2-step control, continuous PI control, switching PI control (PWM). Output: continuous in the range 0 to 100% or switching ON/OFF.

Duurzaam product

Dit product is aangemerkt als duurzaam doordat aan de ETIM productgroep "Ruimtetemperatuurregelaar bussysteem" bij juiste toepassing energiebesparende dan wel energieopwekkende eigenschappen zijn toegekend. Dit leidt tot CO2-reductie.
