Productomschrijving
31106 INTERPACT INS250 3P LASTSCHEIDER
Compact INS250-250A 3P - Lastscheider - Vast - Zwart
Deze Compact INS250 is een 3-polige niet-automatische lastscheider met zwarte draaibediening. De schakelaar is geschikt voor isolatie met positieve contactindicatie, zoals gedefinieerd door de IEC 60947-1- en IEC60947-3-normen. De operationele stroom is 250 A bij 415 VAC in de categorieën AC22A en AC23A. De nominale spanning is 690VAC 50/60Hz of 250VDC. De zwarte draaihendel is ontworpen voor een eenvoudige bediening en hoge prestaties bij het onderbreken van stromen. Compact INS250 is een frontpaneel van klasse II met isolatieniveau conform de IEC 60664-norm.
Specificaties
Algemeen
Ons artikelnummer | 1077399 |
Artikelnummer fabrikant | 31106 |
EAN-code | 3303430311065 |
Artikelklasse (ETIM) | Lastscheider |
Merk | Schneider Electric |
Serie | Interpact |
Type nummer | 31106 |
Omschrijving | COMPACT INS250 3P LASTSCHEIDER ZWART |
Land van Oorsprong | PL |
Technisch
Uitvoering als hoofdschakelaar | Ja |
Uitvoering als werkschakelaar | Ja |
Uitvoering als veiligheidsschakelaar | Nee |
Uitvoering als noodstopinrichting | Nee |
Max. nom. bedrijfsspanning Ue bij AC | 690 V |
Nom. continustroom Iu | 250 A |
Nom. vermogen, AC-23, 400 V | 132 kW |
Aantal polen | 3 |
Aantal hulpcontacten als verbreekcontact | 0 |
Aantal hulpcontacten als maakcontact | 0 |
Aantal hulpcontacten als wisselcontact | 2 |
Motoraandrijving optioneel | Nee |
Motoraandrijving geïntegreerd | Nee |
Uitschakelspoel optioneel | Nee |
Apparaatbouwvorm | Inbouwapparaat vaste inbouw techniek |
Geschikt voor bodemmontage | Ja |
Geschikt voor frontmontage 4-gats | Ja |
Geschikt voor frontmontage centraal | Ja |
Geschikt voor verdelerinbouw | Ja |
Geschikt voor tussenbouw | Nee |
Uitvoering van het bedieningselement | Lange draaigreep |
Vergrendelbaar | Ja |
Aansluitwijze hoofdstroomcircuit | Schroefaansluiting |
Beschermingsgraad frontzijde (IP) | IP40 |
Uitvoering als omkeerschakelaar | Nee |
Bedrijfsspanning (meetspanning) | 690 - 690 V |
Toegelaten korte-duur stroom Icw | 8.5 kA |
Kleur bedieningselement | Zwart |
Aantal schakelaars | 1 |
Nom. continustroom, AC-23, 400 V | 250 A |
Logistiek
Aantal eenheden in artikel | 1 st |
Minimale bestelafname | 1 st |
Standaard voorraadartikel | Nee |
Bruto gewicht | 2,282 kg |
Afmeting verpakking | 17,4 x 16,2 x 13,8 cm |
Volle verpakking bevat | 9 st |
Prijs
Bruto prijs (€) | 344,20 per 1 st |
