Schneider Electric - CEE-koppelcontactstop - PKF32M413

PKF32M413 CEE KOPPELCONT.STOP 32A 3P 110V 4H IP44

PratiKa - Koppelcontactstop - 2P+A - 32A - 100-130V AC - 4h - IP44

This PratiKa industrial wander socket with captive screws connection is straight. It has 2P+E pole, rated current is 32A and the operating voltage is 110VAC. The dimensions of the wander socket are (W) 98mm x (H) 98mm. The degree of protection is IP44 and IK08. The fire resistance is 850°C. The cable entries are for flexible or rigid cables. The size of the cable entries in 32A is 11.5mm to 21mm for 2.5mm² to 10mm² cables. The color of the socket is grey (RAL 7035) with yellow easy identification of the operating voltage. The frequency is 50Hz or 60Hz. The clock position of contact is 4h.
